Fresatricia portale fisso ed a portale mobile (4)

SCHEDA TECNICA CNC – Fresatrice a portale a portale Marchio TRIMILL Tipo VF3016 Data di costruzione 2017 Controllo HEIDENHAIN iTNC530 HSCI Viaggio Asse X (longitudinale): 3.000 mm Asse Y (trasversale): 1.600 mm Asse Z (verticale): 1.200 mm Asse B (testa di fresatura ad asse girevole) +/- 100 Asse C (testa di fresatura asse di rotazione) +/- 240 Struttura / Concetto di asse Servomotori AC con controllo digitale per tutti gli assi Azionamento a portale dell'asse X Azionamento a pignone e cremagliera nell'asse X, senza gioco grazie ai motori elettricamente precompressi e raffreddati ad acqua 2 viti a ricircolazione di sfere ciascuna negli assi Y e Z Le guide di tutti gli assi lineari sono progettate come guide a rulli precompressi Compensazione del peso idropneumatico dell'asse Z tramite 2 cilindri Componenti fissi del telaio in fusione minerale, compone ...

x-axis: 3000 mmy-axis: 2000 mmz-axis: 1100 mmdistance between columns: 3800 mmspindle motor: 18 / 23 kWspindle turning speed range: 18000 U/minrapid traverse: - m/mintable-size: 2800 x 2000 mmworkpiece weight: 7,5 t/m²Control: Heidenain TNC 640 workpiece width - max.: 3650 mmA-Axis: +/- 115 / 0,001 °c-axis: 360 / 0,001 °total power requirement: - kWweight of the machine ca.: - tdimensions of the machine ca.: - mMachine equipped with:- 5-axis machining centre- Heidenhain 640 iTNC CNC control (15.1” LCD) with Kinematics Opt. function- 24-position tool changer (HSK A63)- (German) Cytec S8 A/C milling head (18,000 rpm, 56/72 Nm, integrated)- Linear guides with rollers for the X/YU/Z axes- Heidenhain linear scales for the X/YU/Z axes- Coolant supply through the spindle, 20 bar- Air blow-off device on the spindle- Blum TC-60 workpiece measuring system- Blum NT-A3 tool measuring system- Sp ...

x-axis: 4000 mmy-axis: 3200 mmz-axis: 1200 mmdistance between columns: 2700 mmspindle motor: 50 / 65 kWspindle turning speed range: 15000 U/mindistance spindle nose and table: 200 - 1400 mmrapid traverse: m/mintable-size: 4020 x 2400 mmworkpiece weight: 15 tControl: Heidenhain TNC 640 total power requirement: - kWweight of the machine ca.: 44 tdimensions of the machine ca.: - mMachine equipped with:X, Y, Z, B, C five axes simultaneous movement control- CNC control Heidenhain TNC 640- 40-position tool changer (HSK-A100)- 2-axis milling head TCH-19F-- B- & C-Axis- X,Y,Z-axis linear scales- IKZ 20bar- Tool off-set- Oil skimmer- Chip conveyorThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-axis: 5060 mmy-axis: 3200 mmz-axis: 1000 mmdistance between columns: 2700 mmspindle motor: 22/26 kWspindle turning speed range: 6000 U/minrapid traverse: 15 m/mintable-size: 5000 x 2400 mmworkpiece weight: 18 tControl: FANUC 31i-MB total power requirement: - kWweight of the machine ca.: 45 tdimensions of the machine ca.: 12,6 x 6,5 x 4,15 m- CNC Control FANUC 31i-MB- Tool Changer 32-fold (BT 50)- 3 axes linear scales- Semi-auto universal head (C axis auto 5 degree indexing)- Extension head- Spindle oil cooler- Air conditioner for electrical cabinet- Hydraulic oil cooler- no coolant thru spindleThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
