Cesoie per profilati in acciaio KNUTH HPS 55/110D

Round bar steel: 40 mm Square edge steel: 40 mm L-beam: 10 mm The machine is in extremely good condition, as it was not used much by us.
We can also organize a complete transport for you.

The price is net plus VAT.

Punching force: 55 t

Max. punching capacity: Ø40 mm for 10 mm steel

Alternative: 20 × 20 mm solid material

Projection: approx. 250 mm

Stroke: 60 mm

Stroke rate: approx. 37 strokes/min (at 20 mm stroke)

Table size: approx. 550 × 250 mm

✂️ Flat steel shears

Max. 300 × 15 mm (width × thickness)

Alternative: 200 × 20 mm

Knife length: approx. 305 mm

Steel bar shears

Round steel: Ø40 mm

Square steel: 40 mm

Profile shears (angle steel)

90°: up to 120 × 120 × 10 mm

45°: approx. 70 × 70 × 7 mm

Notching station

Max. sheet thickness: 10 mm

Notch S6264672 size: approx. 42 × 42 S6264672 mm

⚙️ Drive & Machine

Hydraulic motor: 5.5 kW

Dimensions: approx. 1480 × 1800 × 1730 mm

Weight: approx. 1300 kg

Facilities

5 workstations (punching, flat steel, profile, bar steel, notching)

Peddinghaus-compatible stamps/dies

Stepless stroke adjustment

Hydraulic overload protection
seller offer No. resale 168752684
