SBM SMR 10/5/4 Molini a proiezione
usatoVenditore verificato
Richiedi il prezzo
Direttamente al venditore
1 / 7
Dati tecnici
· ID 170394669Macchine usate
- Condizioni
- usato
- Anno di costruzione
- 2007
- Ubicazione
- 7.... Karlsruhe
Identifikation
ProduttoreSBM
ModelloSMR 10/5/4
Numero articoloZE 140
Technik
Quantità1
Descrizione
TECHNICAL SPECIFICATIONS
Manufacturer: SBM Mineral Processing
Description: Reversible impact crusher
Type: SMR 10/5/4 (SMR-1)
Year of Make: 2007
Drive power: 110 kW
Throughput capacity: max. approx. 80 t/h (depending on feed material)
Maximum feed size: 10 to 150 mm
Target grain size: 0 - 32 mm
Rotor diameter: 1,000 mm
Crusher inlet: 260 x 520 mm
Number of blow bars: 4 pcs.
Weight (crusher): approx. 8,500 kg
Feed chute: SBM type FRLM 5/15
Nominal width: 500 mm
Nominal length: 1,500 mm
Drive power: 11 kW
SPECIFIC COMMENT
- Incl. drive motor 110 kW
- Incl. steel construction and outlet tray
Manufacturer: SBM Mineral Processing
Description: Reversible impact crusher
Type: SMR 10/5/4 (SMR-1)
Year of Make: 2007
Drive power: 110 kW
Throughput capacity: max. approx. 80 t/h (depending on feed material)
Maximum feed size: 10 to 150 mm
Target grain size: 0 - 32 mm
Rotor diameter: 1,000 mm
Crusher inlet: 260 x 520 mm
Number of blow bars: 4 pcs.
Weight (crusher): approx. 8,500 kg
Feed chute: SBM type FRLM 5/15
Nominal width: 500 mm
Nominal length: 1,500 mm
Drive power: 11 kW
SPECIFIC COMMENT
- Incl. drive motor 110 kW
- Incl. steel construction and outlet tray
