Flexo Printing Machine WINDMöLLER & HöLSCHER ASTRAFLEX
macchine per la stampa / presse: flexo e rotocalco
Number of colors: 8, max. mechanical machine speed: 460m/min, gear pitch: 10mm, print length: 300-1200mm, max. print width with endless sleeve technology: 1270mm, max. print width without endless sleeve technology: 1250mm, max. material width: 1320mm, max. unwind roll diameter: 1000mm, max. rewind ...
Fabbricante: Windmöller & Hölscher
Modello:ASTRAFLEX
Tipo di macchina: Flexo Printing Machine
Numero di articolo: 170052425
Quantità: 1
Data: 15.08.2026
Anno di fabbricazione: 2001
Luogo:
Germania
Deutschland
Prezzo:
Macchina in azione:No
Seller-item-No.:INNO32177
Number of colors: 8, max. mechanical machine speed: 460m/min, gear
pitch: 10mm, print length: 300-1200mm, max. print width with endless
sleeve technology: 1270mm, max. print width without endless sleeve
technology: 1250mm, max. material width: 1320mm, max. unwind roll
diameter: 1000mm, max. rewind roll diameter: 1000mm, sleeve inner
diameter: 76mm, sleeve outer diameter: 85mm, max. roll weight: 1,24t,
web tension ranges, unwinding without draw: 40-350N, unwinding with
draw: 25-350N, rewinding without slitter: 25-450N, rewinding with
slitter: 30-450N, draw: 25-450N, suitable materials: LDPE, PP, PA:
20-150µm, HDPE, OPP: 12-100µm, max. laminated films: 120µm, paper:
30-120g/m². Equipment: unwinder, rewinder, control panel, corona
treatment, Turboclean ink supply system, numerous printing cylinders,
anilox rollers and additional accessories, with documentation. An
on-site inspection is possible.
