altre macchine per lavorazione del legno usati in vendita (1,356)

X=3700mm Y=1440mm, Z=150mmMoving speed: X: 80 m/min, Y: 80 m/min, Z: 20 m/min8 supports with vacuum cups, pneumatic clamping8 fences at the rear8 fences in front2 left fences and 2 right fences6 rails for panel loading with pneumatic liftingPositioning the vacuum cups using a laser1 connection for templatesVacuum pump with flow rate 100 m3/hConfiguration V25,H8X/6Y, N1 X-Y 90?, F1-HSK63-15KW,F1-HSK63-9KW, C axis, W14 rearMain motor 15 kW, 1250-24000 rpm, air-cooled, 360? C-axis, C-axis interpolation axis, HSK 63 mountingC axis extension for flex-5 aggregateMain motor 9 kW, 1250-24000 rpm, air cooled, HSK 63 mountingTool changer operating in X direction with 14 positions, rear mounted2 x 4 vertical X drilling pins, 2 x 3 vertical Y drilling pins14 horizontal drilling spindles90? groove saw X-Y directionPC 85 power control software with:Woodwop: workshop-oriented programming systemImport 2 ...

Working area: X 5200 x Y 1260 mmHeading of main spindle: X 5709 mm, Y 1650 mm8 workpiece consolesEquipment:Drilling unit with 18 spindles, 12 vertical sp?ndles, 6 horizontal spindles (4 in direction X , 2 in direction Y )Grooving sawMilling motor 11 kW, 20000 rpm max, HSK-F 63 take-up, liquid-cooled, 5-axis controlledTool changer with 16 positionsLaterally positioned changer with 8 positions PC control

Workpiece thickness: 8 - 50 mmEdge thickness: Coil edges 0.4 - 3 mmFeed speed 10 m/minEquipment:manual height adjustment.Joint milling unit, 2 motors Panel edge heatingGluing area Pressure zone 1 driven and 2 non-driven rollersEnd trims, 2 x 0,8 kW motors, straight and chamfer 15?Top and bottom trimmingProfile scraping unit for PVC edgingGlue scrapers

Workpiece thickness: 8 - 60 mmWorkpiece overhang: 38 mmEdge material of the roll: 0.4 - 3 mmEdge material in strips: 0.4 - 6 mm.Min. workpiece width: 70 mm (with thickness 8-22 mm), 120 mm (with thickness 23-40 mm), 150 mm (with thickness 41-60 mm)Feed speed: 11 m/minMachine equipment:Joint milling unit, 2 x 2.2 kW motorGluing unit with workpiece edge preheatingPressure zone with driven main pressure roller and 2 non-driven pressure rollersHood unit, 2 x 0.18 kW, pneumatic adjustment phase/straightRadius and fine milling unit, 2 x 0.27 kWForm milling unit 1 x 0.35 kWProfile scrapersGlue joint scrapers

Panel thickness: 8 - 50 mmThickness of the edges: 0,4- 3 mmFeed speed 8 - 11 m / minPU pressure rollersEquipment:Squaring unit, 2 motors 2,2 kWPanel edge heatingEdge magazine for coil and stripsHot melt application with rollerAirtec AT4510 unitThe Airtec aggregate is positioned so you can use Airtec or the standard glue potMotorized side pressure unitEnd trims, 2 motors, pneumatic positioning straight and with chamfertrimming unit above / belowContour trimming unitProfile scraping unitGlue scraping unitPolishing unitDetergent spray systemcentral lubrication

Fixed side at the leftFeedspeed 18 - 25 m/minWorking width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mmPanel overhang 30mmPanel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations)Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mmCoil diameter 830 mmEquipment:Sprayers release agentSquaring device with 2 motors each 3 kWEdge heatingEdge magazine for 2 coils, guillotine for edges up to 3 mmGlueing part A20 with quickmelt applicationLateral pressure zone K, 1 driven and 6 after pressing rollersEnd trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kWContour trimming, 2 exchange unitsProfile scraping PN10Flat scrapers FA11Sprayers cleaning agentBuffingAutomation package straight/chamfer:-Automatic adjustment infeed fence-Automatic setting of pressure rollers-Pneumatic setting of end trims-Pneumatic setting of rough trims-Automatic setting of chamfer/ra ...

Single sided edge bander with hot melt, fixed side at the right, pre-milling unitEdge thickness: 0,4 to 12 mmWorkpiece thickness: 8 - 60 mmFeedspeed 8-20 m/min (limited to 10 m/min using the contour trimming)Workpiece transport by chain, top pressures with rubber rollersSound enclosure over all trimming motorsEquipment:Adjustable fencePre-milling with 2 shapers, each 2,2 kWCoil and strip magazine Hot melt unit, Quickmelt type Pressure zone with1 driven and 2 non-driven pneum. Loaded rollersEnd trims, 2 x 0,35 kW motors, straight and chamfer 15?Top/bottom trimming, motors 2 x 0,35 kWRadius trimmmingContour trimming unit, leading and following edge, 2 x 0,35 kWRadius scraping unitGlue scrapersBuffing unitControlls PC 20+

Fixed side at the leftFeedspeed 18 - 25 m/minWorking width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mmPanel overhang 30mmPanel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations)Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mmCoil diameter 830 mmEquipment:Sprayers release agentSquaring device with 2 motors each 3 kWEdge heatingEdge magazine for 2 coils, guillotine for edges up to 3 mmGlueing part A20 with quickmelt applicationLateral pressure zone K, 1 driven and 6 after pressing rollersEnd trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kWContour trimming, 2 exchange unitsProfile scraping PN10Flat scrapers FA11Sprayers cleaning agentBuffingAutomation package straight/chamfer:-Automatic adjustment infeed fence-Automatic setting of pressure rollers-Pneumatic setting of end trims-Pneumatic setting of rough trims-Automatic setting of chamfer/ra ...

Workpiece thickness: 8 - 90 mm, electronically adjustableFeed rate: 18-32 m/min frequency controlledEdge thickness: 0.3 - 3 mm for roll edges, strips up to 20 mmEquipment:Inlet guide automatically adjustable via the control, extension 500 mmJoint milling unit: 2 x 3.0 KWworkpiece preheatingGluing unit A34edging magazine for rollPressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the controlCutting unit WK14, straight, 2 motors 0.8 kWPre-milling unit: 2 x 1.5 KW, pneumatic adjustmentForm milling unit FF 12 automatic, 2 motors 0.4 kWradius/phase milling unit FF12 automatic 4 motors 0.4 KWuniversal milling aggregate controlled UF11, 4 kWProfile scrapers PN20Glue scrapersNozzles for detergent and anti-stickPolishing unitControl: Power Control PC22

Gantry-type, 3-axis CNC machining centreWorking area (type 2132): approx. 3300 x 2100 mmVacuum table with multiple switchable zonesInput: AES lifting table for automatic sheet loadingOutput: conveyor belt with label printer (labels are printed and applied manually)Main spindle: HSD ES929, HSK-F63 mount, 7.5 kW (9 kW), speed up to 24,000 rpm, 800 Hz, 380 VMain spindle overhauled in 2023Drilling unit with 16 spindles: 6 vertical spindles in X, 4 vertical spindles in Y, 2 double horizontal spindles in X, 1 double horizontal spindle in YSlotting sawTool changer with 12 positionsVacuum: Becker vacuum pumps, system approx. 500 m?/hControl: OSAI control system with AES ProcessController, operation via console with touchscreen and keyboardOperating hours: approx. 2,100 h (machine life), main spindle overhauled at approx. 1,360 h

Fixed side at the leftPanel thickness min/max: 16/45 mmMin. panel width: 150 mmLateral panel support for panel width up to 900 mmMin/max. panel length: 700 / 3100 mmMax. laminate overhang: 110 mmMax. laminate thickness: 0,8 mmRadius min/max: 6 / 22 mm (depends the laminate)Feedspeed max. 18 m/minTop pressure by beltEquipment:Infeed fence, adjustable, defines the panel overhang2 x trimming unit 0,4 kW, HSK 25 toolholder1 x PVAc glue application5 x glue nozzle, adjustable1 x hot air blower3 x IR heating on top (55 cm length), 3 x bottom (90 cm length)Postforming zone 1,8 m. lengthVarious pre-installed profiling sets 1 x top trimmer 0,4 kW

Bridge type Capacity for all units: 3300 x 1100 mm(alternating: 2 x 1025 x 1100 mm)Capacity for routing with tooldiameter 25 mm: 1550 mmWorkpiece thickness up to 300 mm (stroke Z-axis 600 mm)Speed in X and Y: 60 m/min, Z: 25 m/min, Vector: 85 m/min6 Support rails with LED positioning indicationVacuum: 100/140 m3/hControlls: Powercontrol PC85Waste/chip removal belt in machine baseMachine pneumatically prepared to take pneumatic clamps, 3 pcs clamps includedDrilling unit V9/H4, 13 spindles, motor 2,2 kWMain spindle DRIVE5C+, 5-axis, 10 kW, HSKF63 taper, speed 1000 to 24000 r/min, tooldiameter up to 180 mm for routing, 350 mm for cutting14-fold rotary toolchanger and pick-up place for a sawbladeWoodwop software

Working field: axis x: 2310 mm, axis y: 628 mm, axis z: 90mmMax programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/minDrill chuck: diameter 10 mmSpindle speeds: 4000 rpmGrooving saw: diameter 120 mmDrill spindles: 4 horizontal spindles in X,12vertical spindles in X lineWorking air pressure: 6 barMax consumption of compressed air: 0,75 NL/cycleInstalled power: max 7.5 kWCapacity of vacuum tools: 40 m?/hCNC:screen: monochromatic 9?Floppy disk unitPLC for control of the machine cycle

Working field: axis x: 3200 mm, axis y: 944 mm, axis z: 110mmMax programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/minDrill holder: diameter 10 mmSpindle speeds: 4000 rpmGrooving saw: diameter 120 mmDrill spindles: 24 horizontal spindles in X,10 vertical spindles in X lineWorking pressure air pressure: 6 barInstalled power: max 25 kWCapacity of vacuum tools: 40 m?/hCNC:screen: monochromatic 9?Floppy disk unit

Working area: X 5005 x Y 1520 mm x Z 200 mmMain spindle travel: X 5910 mm, Y 1815 mm, Z 655 mm.Travel speed: X 80 m/min, Y 80 m/min, Z 25 m/min8 workpiece consoles with automatically positioning vacuum cupsEquipment:Drilling unit with 19 spindles, 7 vertical spindles in X, 6 vertical spindles in Y, 2 double horizontal spindles in X, 1 double horizontal spindle in Y Slotting sawMilling motor 12 kW, 1000?24,000 rpm, HSK-F 63 mounting, liquid-cooled, 5-axis controlledTool changer with 22 positions Vacuum pumps with 2 x 100 m?/h capacityPC controlMasterwork software Integrated waste conveyor

Working width 180 - 3200 mm, electronic setting Sieb & MeyerFixed side at the leftChain transport, 80 mm wideInfeed for panels of about 1 m.Top pressure by driven beltsMax. workpiece thickness: 80 mmFeedspeed 7 - 35 m/min, motor 2,2 kWPop-up dogs every 1m10Equipment left / right:1 st postFront: 1+1 Jump scorer, motor 1,5 kW, 100 Hz, joined to 1+1 Hogger, motor 3 / 4,4 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 Hz2nd postFront: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzRear: 1+1 Fixed milling, tilting, motor 2,2/3,3 kW, 50/100 Hz3th postFront: 1+0 Jump milling, tilting, motor 2,2/3,3 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzAll units with horizontal/vertical adjustment and Siko read-outOutfeed chain approx. 80 cm lengthSound and safety enclosures

Right-hand versionCutting-off saw: 1.5 kW2 x horizontal shaft: 2 x 1.5 kW1 x vertical shaft, diameter 50 mm, length 160 mm, 2.2 kW

Right-hand versionWorkpiece dimensions: max. length 3000 mm, min. 250 mm, max. thickness 100 mm, min. 30 mm, width 200 mmOverhead cutting saw, 3 kW, 3000 rpm, manual horizontal movement over 120 mm, 400 mm blade, cutting height 100 mm1 vertical shaft, 340 mm long, 40 mm diameter, 7.5 kW, 3100 rpm, suction port with 150 mm diameter (x2), max. tool diameter: 320 mmCarriage with pneumatic clamping1100 x 500 mm tableStop, positioning from -45? to 45?Motorized carriage with electronic control 2-32 m/min

Semi-automatic

Edgebander prodotto nel 2008. Questo BIESSE Edge Stream B1 dispone di un set completo di utensili tra cui una macchina per incollare PU, un'unità di pre-fresatura, un tagliafilafildi e un'unità di fresatura fine. Include anche unità di arrotondamento e raschiature per bordi, insieme a spazzole oscillanti e un riscaldatore per bordi. Se desideri ottenere capacità di bordatura di alta qualità, considera la macchina BIESSE Edge Stream B1 che abbiamo in vendita. Contattaci per ulteriori dettagli.

Linea di produzione del legno prodotta nel 2023. Questo ISM ATM-01 è una linea di produzione automatica su misura progettata per la produzione completamente automatizzata di schermi da giardino in legno da assi singole. Dispone di scarica automatica e impilamento delle schermate finite, pile inclinabili per un'elaborazione efficiente ed è regolabile per cinque diversi tipi di schermi. Se desideri ottenere capacità di lavorazione del legno di alta qualità, considera la macchina ISM ATM-01 che abbiamo in vendita. Contattaci per ulteriori dettagli.

Un deposito di tronchi completo e ben conservato. Alimentazione per legname rotonda completamente inclusiva per tronchi corti e lunghi, con taglio e selezione per legname lungo, tornatore di tronchi, metal detector, sistema di scorteccia Esterer ER 90, riduttore di radici Bruks e linea di smistamento, costruite in modo molto robusto. Smaltimento completo e inclusa la sottostruttura in acciaio e tutti i cavi fino all'apparecchiatura. Sistema di controllo completo e cabina operativa con stazione operatoria come soluzione container. Semplicemente completate Smantellare da solo

Produttore: MICROTEC Modello n.: GOLDENEYE 600 Anno: 2014 Condizione: Usato Numero di magazzino: 9397 L'offerta include: Pannello touch MICROTEC Armadio di controllo Attrezzatura: Documentazione tecnica

Produttore: FORMAT 4 Modello: Tempora 60.06 GlueBox X-motion Anno: 2023 Condizione: Usato Numero di magazzino: 9353 Altezza di attacco: 10-60 mm Spessore del bordo: 0,4-3 mm Velocità di avanzamento: 10 m/min Minimo. Lunghezza del materiale: 140 mm

Scanner di qualità prodotto nel 2014. Questo MICROTEC GOLDENEYE GLD 600 DSC è progettato per l'ispezione di grandi pannelli e tavole fino a 1,8 metri di larghezza. Integra telecamere multisensore geometriche, visive e a raggi X per valutare sia le proprietà esterne che interne del legname, fornendo una valutazione completa della qualità del materiale. Se desideri ottenere capacità di ispezione di alta qualità, considera la macchina MICROTEC GOLDENEYE GLD 600 DSC che abbiamo in vendita. Contattaci per ulteriori dettagli.

Questo FORMAT4 TEMPORA 60.06 TEMPORA 60.06 glueBox x-motion edgebander è stato prodotto nel 2024. Dispone di un caricatore girevole con un diametro di 750 mm per il bordo di materiali da 0,4 a 3 mm, un'unità applicabile GlueBox e unità di lucidatura superiore e inferiore. La macchina include un avanzato controllo x-motion Plus con uno schermo SmartTouch da 15 e un'unità di fresatura multifunzionale per una lavorazione precisa dei bordi in plastica. Contattaci per maggiori informazioni su questa macchina.

Inv. Num. : 8894 Tipo: B24-TH300 DX/DW PU Produttore: H&H Maschinenbau Creato: 2020 Parametri: Peso: 498 kg Attrezzatura: Macchina per fusione PUVS 280 P per 20 kg di fuso adesivo PUR

Inv. Num. : 8874 Tipo: TRIATHLON 1487 V Produttore: HOLZHER Creato: 2003 Parametri: Altezza di rimontaggio: 55 mm Dimensioni della macchina: 7500 x 1300 x 1800 mm

Numero Inv. : 8663 Tipo: Opticontrol Produttore: Weinig Generato: Parametri: Diametro massimo dell'utensile: 300 mm Lunghezza massima dell'utensile: 330 mm

Numero inv. : 8465 Tipo: SP-300x4C Produttore: Prochera Creato: 2015 Parametri: Velocità massima: 1500 1/min Avanzamento di lavoro: 0-23 m/min Larghezza massima: 300 mm Altezza massima: 100 mm Numero di spazzole: 4 Peso: 1500 kg Attrezzatura: Spazzole di ricambio
