Macchine insacchettatrici AMTEC TB-3S L HS

Automatic packing machine for filling and packing tea into tea into common rectangle tea bags with final packing of the tea bag into a 3-side sealed sachet. Including Volume dosing unit and tag system. Tag system: both sides (label-thread and thread-bag) by heat sealing. Device for grouped bag output. PLC controlled, operation via touch screen. - Specifications: max. speed of the machine in neutral: 115 cycles per minute | dosing volume: max. 10cm? | tea bag dimensions LxW: 65x62.5 mm | roll width tea bag material: 125 mm (optional 140 mm) | suitable tea bag material: 16.5-21g/m?, one side heat sealable | 3-side sealed sachet dimensions LxW: 82x75 mm | sachet material: heat sealable mono films or laminated composite film | label (LxW): 26x24 mm | thread length: 220 mm | power supply: 220/380V | power consumption: 3kW | compressed air required: 0.6 MPa | compressed air consumption: 100-300l/min | machine dimensions LxWxH: 2840x122x2205 mm | B5817119 weight: 1410kg.

Please B5817119 note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
seller offer No. resale GE-TEA-LRGBAG02
