Automatic packing machine for filling and packing tea into tea into
common rectangle tea bags with final packing of the tea bag into a
pillow bag (up to 5 tea bags in one sachet possible). Including Volume
dosing unit and tag system. Tag system: both sides (label-thread and
thread-bag) by heat sealing. - Specifications: max. speed of the
machine in neutral: 115 cycles per minute | dosing volume: max. 6cm? |
tea bag dimensions LxW: 62.5x50 mm | roll width tea bag material: 125
mm | suitable tea bag material: 16.5-21g/m?, one side heat sealable |
pillow bag dimensions LxW: 100x130 mm, L is adjustable (vffs) | pillow
bag material: heat sealable mono films or laminated composite film |
label (LxW): 26/28x24 mm | thread length: 210 mm | power supply:
220/380V | power consumption: 2W | machine dimensions LxWxH:
1400x905x2475 mm | weight: 910kg.
Please note that B5817119
our new prices are often below the usual used prices. Please feel free
to inquire and tell us your packaging task. - Usually 30-50 different
new machines are available immediately from stock. In addition, we
have very short delivery times from approx. 3 weeks for customized
machines. Deviations from the sample photo are possible. - All
machines are available with full warranty.
