IBERDRILL B 60 Trapano a colonna

bore capacity in steel (diameter): 60 mm
bore capacity in cast iron (diameter): 70 mm
threading cutting capacity:: M50
throat: 420 mm
bore stroke: 260 mm
spindle taper: MK 5
feed range - spindle: 0,1-0,2-0,3-0,4-0,5-0,6 mm/U
spindle turning speed range: 64 - 1210 U/min
transmission ratio: 12 Stufen
column diameter: 220 mm
table surface area: 600 x 600 mm
total power requirement: 4 kW
weight of the machine ca.: 0,82 t
dimensions of the machine ca.: 0,7 x 1,2 x 2,7 m
Equipment:
- Gears made of hardened and ground steel
- Front speed selector lever
- Gear lubrication by automatic oil pump
- Integrated coolant device
- Machine lamp
- Rotatable and tiltable table
- Automatic feed with electromagnetic clutch
- Handwheel for manual fine feed
- automatic tool ejector
- Integrated electrical controls in the drill head
- Pushbutton for EMERGENCY STOP
- Switch for right / left rotation
- Height-adjustable chip protection hood with microswitch
- CE mark
