Smerigliatrici a nastro JOHANNSEN T96
macchine per lavorazione del legno / rettificatrici legno / Smerigliatrici a nastro
gebr. Long belt grinding machine JOHANNSEN T96 YOC 1994 Total connected load: 5.7 kW / Rated current: 12.5 A Motor power: 4.0 / 5.5 kW 2 belt speeds Table size: 278 x 95 cm electr. Table lift Belt dimensions: 150 x 7,800 mm Maximum usable sanding belt length: 260 cm Large offset (right): 1,000 x ...
Fabbricante: JOHANNSEN
Modello:T96
Tipo di macchina: Smerigliatrici a nastro
Numero di articolo: 169314719
Quantità: 1
Data: 12.04.2026
Anno di fabbricazione: 1994
Luogo:
Germania
85416 Oberhummel
Prezzo: 3,950 EUR
Macchina in azione:Sì
gebr. Long belt grinding machine
JOHANNSEN T96
YOC 1994
Total connected load: 5.7 kW / Rated current: 12.5 A
Motor power: 4.0 / 5.5 kW
2 belt speeds
Table size: 278 x 95 cm
electr. Table lift
Belt dimensions: 150 x 7,800 mm
Maximum usable sanding belt length: 260 cm
Large offset (right): 1,000 x 310 mm
Left offset: 550 x 310 mm
Pneumatic grinding unit (pneumatic pressure)
incl. 2 sanding shoes: 300 + 450 mm (incl. suction device)
Suction arm for vacuuming the sanding shoe
Vacuum suction clamping device (pneum. workpiece clamping) with 8 suction cups incl. vacuum pump
Turntable (stroke pneumatic)
Sanding board with stop
Selector switch for clockwise/counterclockwise rotation
Suction nozzle right + left + sanding shoe (120 + 140 + 80 mm)
Dimensions: 255 x 430 cm
Weight: 900 kg
Machine dimensions (approx. dimensions)
W: 430 cm D: 162 cm H: 153 cm
JOHANNSEN T96
YOC 1994
Total connected load: 5.7 kW / Rated current: 12.5 A
Motor power: 4.0 / 5.5 kW
2 belt speeds
Table size: 278 x 95 cm
electr. Table lift
Belt dimensions: 150 x 7,800 mm
Maximum usable sanding belt length: 260 cm
Large offset (right): 1,000 x 310 mm
Left offset: 550 x 310 mm
Pneumatic grinding unit (pneumatic pressure)
incl. 2 sanding shoes: 300 + 450 mm (incl. suction device)
Suction arm for vacuuming the sanding shoe
Vacuum suction clamping device (pneum. workpiece clamping) with 8 suction cups incl. vacuum pump
Turntable (stroke pneumatic)
Sanding board with stop
Selector switch for clockwise/counterclockwise rotation
Suction nozzle right + left + sanding shoe (120 + 140 + 80 mm)
Dimensions: 255 x 430 cm
Weight: 900 kg
Machine dimensions (approx. dimensions)
W: 430 cm D: 162 cm H: 153 cm
