Ram-Type Floor Boring and Milling M/C SKODA W 180 NC
macchine per lavorazione dei metalli / altre macchine per lavorazione dei metalli
spindle diameter:180 mmx-travel:6.000 mmy-travel:2.900 mmtotal power requirement:95 kWMachine Technical Data·Machine weight: approx. 130 t including accessories·Z travel (ram): 1250 mm·W axis (spindle): 1000 mm·Sleeve extension: 1250 mm·Sleeve dimensions: 450 x 450 mm·Boring spindle stroke: ...
Fabbricante: SKODA
Modello:W 180 NC
Tipo di macchina: Ram-Type Floor Boring and Milling M/C
Numero di articolo: 170171055
Quantità: 1
Data: 10.09.2026
Anno di fabbricazione: 1997
Prezzo:
Macchina in azione:Sì
Seller-item-No.:3402-260108
spindle diameter:180 mm
x-travel:6.000 mm
y-travel:2.900 mm
total power requirement:95 kW
Machine Technical Data
·Machine weight: approx. 130 t including accessories
·Z travel (ram): 1250 mm
·W axis (spindle): 1000 mm
·Sleeve extension: 1250 mm
·Sleeve dimensions: 450 x 450 mm
·Boring spindle stroke: 1000 mm
·Boring spindle speed: 920 rpm
Rotary Table:
·Motor driven rotary table
·IOS 40
·CNC control
·2 axes B and V
·Rotary table size: 3000 x 3500 mm
·Rotary table CNC IOS 40 NC
Indexing and Accuracy:
·Infinitely adjustable
·Diameter related
·Indexing: 4 x 90 degrees up to 360000
·Angular resolution: 0.001 degrees
Travel Ranges:
·Longitudinal cross travel: 1230 mm
Load Capacity:
·Maximum rotary table load: 40 t
Clamping Plate:
·Clamping plate: 3 x 8000 x 2000 mm
x-travel:6.000 mm
y-travel:2.900 mm
total power requirement:95 kW
Machine Technical Data
·Machine weight: approx. 130 t including accessories
·Z travel (ram): 1250 mm
·W axis (spindle): 1000 mm
·Sleeve extension: 1250 mm
·Sleeve dimensions: 450 x 450 mm
·Boring spindle stroke: 1000 mm
·Boring spindle speed: 920 rpm
Rotary Table:
·Motor driven rotary table
·IOS 40
·CNC control
·2 axes B and V
·Rotary table size: 3000 x 3500 mm
·Rotary table CNC IOS 40 NC
Indexing and Accuracy:
·Infinitely adjustable
·Diameter related
·Indexing: 4 x 90 degrees up to 360000
·Angular resolution: 0.001 degrees
Travel Ranges:
·Longitudinal cross travel: 1230 mm
Load Capacity:
·Maximum rotary table load: 40 t
Clamping Plate:
·Clamping plate: 3 x 8000 x 2000 mm
