231 KRONES macchina utilizzata in vendita

Linea di imbottigliamento, composta da: 1. Depalletizzatore/Depalletizzatore Produttore: Pack und Palettiertechnik Rudolf Steinle Gersthofen GmbH Tipo: RAPID-EK Anno di produzione: 1993 Pressione dell'aria: 6 bar Connessione: 220/380 V, 50 Hz Controllo: 24 V DC 2. Disimballatore Produttore: Radenska & Steinle (RS) Tipo: ARO-P3 Anno di realizzazione: 1995 Pressione dell'aria: 6 bar Connessione: 380 V, 50 Hz Potenza: 3 kW 3. Lavatrice per casse Produttore: Radenska & Steinle (RS) Tipo: SPN-2S Anno di realizzazione: 1995 Connessione: 380 V, 50 Hz Potenza: 8 kW 4. Lavatrice di bottiglie Produttore: Schymanski GmbH (MAG) Tipo: SIRIO 8-24 Anno di costruzione 2000 Connessione: 400 V, 50 Hz 5. Ispettore di bottiglie Produttore: miho Inspektionsysteme GmbH Tipo: DAVID Anno di realizzazione: 2002 Connessione: 230 V, 50-60 Hz 6. Linea di riempim ...

Il Krones VarioFlash B è un flash pasteuriser altamente efficiente per il trattamento termico dei prodotti. È stato sviluppato appositamente per il riempimento microbiologicamente sicuro di birra, bevande miste, vino e spritzers Gamma di prestazioni: l'intera famiglia copre da 1.800 a 60.000 litri all'ora. La variante di piccole dimensioni presentata nel 2019 è precisamente ottimizzata per una gamma di output da 18 a 45 ettolitri all'ora (1.800-4.500 l/h). Progettazione compatta: L'intero impianto KZE della variante piccola è dimensionato in modo da poter entrare in un unico contenitore. Questo rende molto più semplice il trasporto, l'installazione e la messa in servizio in loco. Conservazione delicata: Dotata di un sistema di controllo scorrevole PE (Unità di Pastorizzazione) e di un circuito adatto per acqua calda, la birra viene riscaldata estremamente delic ...

Overview This Krones Linatronic M is an empty bottle inspector for glass bottles, built in 2018. It inspects every empty container before filling and rejects any container that fails one of the inspection stages. The machine combines camera-based base, sealing surface, screw thread and sidewall inspection with high-frequency and infrared residual liquid and caustic detection. Two sidewall modules with four mirror assemblies and four cameras provide a compact full-front view of the container, and the DualFlash neck finish lighting inspects the outer and inner sealing surface separately using two minimally offset lighting angles. Foreign containers are identified at the machine infeed by height, contour and colour detection. Three Ecopush rejection points separate foreign, dirty and damaged containers. The machine is operated from a Krones iPanel CD terminal. Technical data Manufacturer: K ...

Risciacquo Triblock 32 + 32 riempitivi + 8 tappo a vite in plastica Adatto per bevande non gassate in PET

Divisorio adatto per PET e cartoni

Rotary labeling machine for applying paper labels to glass bottles using cold glue. Equipped to label front labels (in 4 formats), neck labels (in 2 formats), and back labels (1 format)., Additional title: cold glue labelling for glass bottles; years of manufacture: 1996 – 2023, Operating hours: 10356, Capacity: 55000 bo/h, Formats: 0.5 l NRW bottles, Material: housing from stainless steel, Position: in a floor-standing cabinet on legs, Base construction: carousel-type machine, Features: Protective enclosures with doors; label magazines; glue pumps; dating (vector laser) with its own control console featuring a touchscreen and monitoring via image recording; control cabinet with touchscreens , Periphery: air blow-off; Syscona fill level control; label inspection; cap inspection with ejector; bottle shape inspection

Numero 1 Linea di archiviazione Combi PET completa di seconda mano Linea completa di riempimento KRONES COMBI PET per acqua ferma Capacità: 25 - 30000bph Anno: 2006-2018

È disponibile una macchina rotativa Krones per l'etichettatura con fascia al manico. Metodo di etichettatura: colla fredda, contenitori: bottiglie di vino/bottiglie di vino frizzante, capacità massima di etichettatura: 7000 bottiglie/h, dimensioni della macchina X/Y/Z: circa 1650mm/1250mm/1700mm, peso: circa 2000kg. Documentazione disponibile. È possibile un'ispezione in loco.

È disponibile una linea completa di pulizia e riempimento delle bottiglie Krones. Portata: 8000 bottiglie/h, passo della giostra: 161mm, diametro della giostra: 1800mm, valvole di riempimento: 50. Si tratta di un monoblocco completo per risciacquare e riempire bottiglie di vetro e plastica. Documentazione disponibile. È possibile un'ispezione in loco.

Da sinistra a destra uwemetzlerdingslebener.de 03687328415

Sensometico con KK u, SV plastica, Disponibile dal 03.2027

È disponibile un depalletizzatore Krones a strati completamente automatico. Formato pallet X/Y: 1200mm/1100mm, altezza massima pallet: 2110mm, corsa pallet: longitudinale, capacità massima di depalletizzazione: 8000 container/h, formati di volume container: 200ml/375ml/750ml/1000ml, intervallo diametro container: 55,5mm-89,5mm, altezza contenitore: 205,5mm-310mm, altezza contenitore: 3290mm, altezza trasporto pallet: 550mm. Dimensioni della macchina X/Y/Z: circa 6300mm/2200mm/3350mm, peso: circa 3800kg. Documentazione disponibile. È possibile un'ispezione in loco.

Disponibilità: immediatamente Tipo: 90 Dimensioni della macchina (LxAs-A): 2,5 x 2,5 x 2,2 m Peso: 4000 kg Documentazione tecnica: disponibile Macchina per l'etichettatura completamente automatica Krones Prontomatic BR720-12-480-6-4-180 Tipo 90: Capacità: 16.000 bottiglie/ora Bottiglia n. 1: 1,0 l bottiglia VDF Diametro: 89,5 mm Altezza: 306,5 mm Etichetta della carrozzeria: 120 x 98 mm Altezza adesiva: 27 mm Etichetta sul petto: 92,5 x 44 mm Altezza adesiva: 183 mm Retro etichetta: 75 x 90 mm Altezza adesivo: 27 mm Bottiglia n. 2: 0,7 l di bottiglia VDF Diametro: 77,5 mm Altezza: 286,5 mm Etichetta della carrozzeria: 120 x 98 mm Altezza adesiva: 30 mm Etichetta di covata: 82,5 x 44 mm Altezza adesiva: 172 mm Retro etichetta: 75 x 90 mm Altezza adesiva: 30 mm La macchina è stata utilizzata senza problemi tecnici fino al 04.2026. Lo smantellamento fu  ...

Overview This Krones Sensometic beer filling system was manufactured in 1998 and was previously installed in a high-capacity beverage bottling line. The machine is designed for the isobaric filling of beer and is equipped with 77 filling valves, enabling high-throughput production. The filler is configured as a filling and capping block and includes two capping units: one for screw caps and one for crown cork closures. Both capping systems are equipped with 12 capping heads, and the closure sorting systems are integrated on the machine. With a designed line capacity of approximately 33,000 bottles per hour, the machine is suitable for large-scale returnable glass bottling operations. The system supports a wide range of bottle formats typically used in the beer industry. Technical Data Manufacturer: Krones Series: Sensometic Model: VPVI 77-103 / KK11 / SV11 Machine type: Isobaric beer fil ...

Overview This Krones rinser-filler-capper block was manufactured in 2001 and consists of a Volumetic filling system combined with a Variojet rinser and a screw-capping machine. The machine is designed for PET multiway bottles (GDB PET-MW) in 1.0 L and 0.5 L formats. The system is equipped with 120 filling valves and 88 rinsing stations. The rinser operates with 2 rinsing channels, currently configured for ClO₂ and fresh water. The machine runs clockwise and achieves a production capacity of up to 32,000 bottles per hour at 1.0 L. The machine will be available from October 2026 and will be exchanged parallel to the installation of the new line.  Technical Data manufacturer: Krones model: Volumetic (filler) / Variojet (rinser) year of manufacture: 2001 filling valves: 120 rinsing stations: 88 rinsing channels: 2 (currently ClO₂ and fresh water) formats: 1.0 L GDB PET-MW 0.5 L GDB PET- ...

Overview This Krones Modulfill filling and capping monoblock, manufactured in 2012, is designed for the filling and closing of glass bottles in beverage production lines. The machine is equipped with 60 filling valves and 12 capping heads and is specified for an output of approx. 15,000 bottles per hour. The machine was observed in operation with a current output of approx. 14,990 bottles/hour. It is adjusted for 0.75 l and 0.33 l glass bottles. The capping machine is suitable for plastic screw caps. The system is operated via a Krones iPanel CD and is installed in a stainless steel and glass safety enclosure. Operating data indicate 41,381 operating hours. Technical Data Manufacturer: Krones AG Machine Type: Filling and capping monoblock Model / Identification: Krones Modulfill Year of Manufacture: 2012 Application: Filling and closing of glass bottles Adjusted to Bottle Sizes: 0.75 l ( ...

Overview  This empty bottle inspector (EBI) was manufactured in 2009 by Germany Krones. The machine is designed for the inspection of empty glass and PET bottles prior to filling in beverage production lines. It was previously used in production and has been professionally dismantled and stored in a warehouse. The machine is available immediately from warehouse. Technical data Capacity: Not provided Formats: 0.75 L Gourmet bottle 0.25 L Gourmet bottle 0.25 L Vichy bottle Application: Inspection of empty bottles prior to filling Configuration: Multiple inspection modules including base inspection, sealing surface inspection, thread inspection, mouth/finish inspection, sidewall inspection, residual liquid detection, foreign container detection, bottle height control (±2.5 mm tolerance) Inspection systems: Base inspection (camera) Sealing surface inspection Thread inspection (conical opti ...

Overview The machine is designed for high-speed wrap-around labeling from the reel. The machine was taken from a production line and is fully functional. It is out of production but available for inspection. Technical Data:  manufacturer: Krones, Germany model: Contiroll HS 810-720     year of manufacture: 2015 neck handling machine, modification possible formats: 1,5L and 2,0L labelling applicators: 1 (wet-glue head), 2 magazines operation Direction: Right-machine,  production Capacity: 50.000/h Worked Labels: IN REEL Electrical Supply: 400 V ± 5%, 50 Hz ± 1%, 3P + N + PE, auxiliary 24 V DC

Overview The machine is designed for high-speed wrap-around labeling from the reel. The machine was taken from a production line and is fully functional. It is out of production but available for inspection. Technical Data:  manufacturer: Krones, Germany model: Contiroll HS 810-720     year of manufacture: 2015 neck handling machine, modification possible formats: 1,5L and 2,0L labelling applicators: 1 (wet-glue head), 2 magazines operation Direction: Right-machine,  production Capacity: 50.000/h Worked Labels: IN REEL Electrical Supply: 400 V ± 5%, 50 Hz ± 1%, 3P + N + PE, auxiliary 24 V DC

Overview This Krones - Linapac F-T-1800 automatic bottle packer was manufactured in 1998 and was previously installed in a returnable glass bottling line. The machine is designed for the automatic packing of filled bottles into beverage crates and is typically positioned downstream of the filler and inspection systems. The LINAPAC packer series is widely used in high-capacity beverage production lines due to its robust design and reliable crate handling. The system supports a wide range of bottle formats and crate types commonly used in the beer and beverage industry. The machine was originally operated in a high-performance production environment and is suitable for integration into returnable glass bottling systems with similar capacity ranges. Technical Data Manufacturer: Krones Model: Linapac F-T-1800 Machine type: Automatic bottle packer Year of manufacture: 1998 Application: Autom ...

Overview This Krones Blitzpac case packer, manufactured in 2003, is designed for the automatic packing of PET bottles into crates. The machine is configured for handling of 1.0 l PET bottles, packed into 12-bottle crates. The machine has a stated design capacity of approx. 2,700 crates per hour. Product handling is carried out by a mechanical / pneumatic matrix gripper system, which lifts multiple rows of bottles and places them into crates. The machine is fully enclosed with transparent safety guarding. Operation is controlled via an integrated MTS 10 HMI panel, with physical push-buttons and emergency stop. Technical Data Manufacturer: Krones AG Machine Type: Blitzpac case packer / bottle packer Machine Description: Blitzpac Einpacker 23/0673/006 Year of Manufacture: 2003 Application: Packing of PET bottles into crates Pack Format: 12-bottle crate Capacity: approx. 2,700 crates/hour Co ...

Carbonation system with integrated buffer tank, for the production of CO2-containing mineral water., Additional title: impregnation plant, Capacity: 20000 l/h, CO2 content: 12 g/l, CO2 carbonisation pressure: 7 bar, Max. tank pressure: 8 bar, Current: 69 A, Voltage: 230/400 V, Frequency: 50 Hz, Heating / Cooling: Connection pressure steam: min. 0.5, max. 1 bar, Water: Connection pressure: min. 4, max. 5 bar, Compressed air: min. 7, max. 10 bar, Length: 2 m, Width: 2,4 m, Height: 2,5 m, Weight: 4000 kg, Operation / Control: Siemens Simatic S5, Features: Saturation Tank (content = 750 l) with fill level detectors as a carbonisation tank, measuring writer (ABB), circulating pump (Hilge), various ventils

Inspection machine for checking empty glass bottles prior to filling. The base, sides and neck of the bottle are inspected. Bottles containing residual detergent from the cleaning process are also detected. An additional inspection unit is positioned upstream of the main inspector, which screens out foreign and defective bottles in advance. The inspection criteria are recorded using cameras as well as RF and IR technology., Additional title: Empty bottle control, Capacity filline line: 12000 bo/h, Current: 6 A, Voltage: 400 / 230 V, Frequency: 50 Hz, Running direction: left -> right, Operation / Control: Simatic S7, Position: in a footed housing, Base construction: straight-running, Features: Control and display panel, housing with safety doors, bottle discharge

Overview The labeler was manufactured in 2012 by the German manufacturer Krones. The machine was regularly maintained by OEM and is still in operation till early 2027. As the selling mineral water company is receiving a completely new bottling line, they are selling the used machines of their current line, which are still in good shape. With the two labelling stations, the machine can label front, back and neck. A date coder is included and installed on the machine. Technical Details Output: 20,000 bph Formats: 0,25l Vichy 0,5l 0,7 and 0,75l GDB and Schlegl Pitch circle diameter: 600 mm No servo drive of the plates Infeed and output direction 90° Rotation: counter clockwise 36,000 operating hours Glue pumps included working direction: counter clockwise

Overview The Krones, Gera, Joha, Markl, Miho filling line for returnable glass bottles was previously used to fill beer in a brewery in southern Germany. Technical Specifications Output: 7,800 bph Producs: Beer and CSD Formats: NRW 0.5 l 0.33 l ring neck 0.25 l LN Machine List  Machine type: Decrater Manufacturer: BMS Year of manufacture: 2012 Machine type: Decapper (Screw Cap) Manufacturer: Rink Decapping in the crate Euro 0,5l in 4x5 crate Year of manufacture: 2012 Machine type: Bottle washer Manufacturer: Gera Year of manufacture: 2024 Machine type: Empty bottle inspector Manufacturer: Krones Model: Smarttronic Incl. Pusher Year of manufacture: 2012 Machine type: Filler Manufacturer: Kosme Model: Isofill G 28/960 28 Valves Year of manufacture: 2012 With Combi Capper 4 heads(Crown Cork and Screw Cap) Capacity: 7,800 bph Machine type: Labeling machine Manufacturer: Krones Model: Robust ...

Panoramica La macchina è progettata per l'etichettatura ad alta velocità avvolgente dal bobinetto. La macchina è stata pretratta da una linea di produzione ed è completamente funzionante. È fuori produzione ma disponibile per l'ispezione. Dati tecnici: produttore: Krones, Germania modello: Contiroll anno di fabbricazione: 2008 applicatori di etichettatura: 2 (teste a colla umida) funzionamento Direzione: Macchina destra, parallela su un lato della macchina Capacità produttiva: 45.000/h Etichette lavorate: IN REEL Alimentazione elettrica: 400 V ± 5%, 50 Hz ± 1%, 3P + N + PE, ausiliaria 24 V DC

Bottle washing machine (with chemical dosing) Manufacturer: Krones Model: Lavatec Kes Year of manufacture: 2000 Performance: 39,000 bottles/h, Additional title: Bottle washing machine, Capacity: 39000 Bottles/h, Length: 12700 mm, Width: 4700 mm, Height: 3500 mm, Formats: 0,33 l Vichy, 0,33 l Euro, 0,35 l Lemonade, and 0,5 l NRW, Operation / Control: Simatic S7-300, Position: free standing, Base construction: Single-end machine, self-supporting housing on dome feet, Features: H2 extraction, label press, bottle tables, ladders, walk-on platforms, various spare parts, another 400 baskets of 22 bottles each Concentrate dosing station, Layer patterns: 22 bottles per basket row

Overview  The machine was built in 2018 by the german manufacturer KRONES and is designed for high-speed wrap-around labeling from the reel. This machine is ideal for bottling lines requiring flexibility across various labeling technologies. The machine was taken from a production line and is fully functional. It is available for inspection and can be disassembled, packed and shipped on request. Technical data  year of manufacture: 2018 Capacity: approx. 20,000 /h Bottle Formats: 0.5 L, 1.5 L PET  Worked Labels: IN REEL Reel Change: Automated Electrical Supply: 400 V ± 5%, 50 Hz ± 1%, 3P + N + PE, auxiliary 24 V DC Protection Class: IP 54 (main panel and motors) Modular Design (Plug & Play): Features automatic docking stations allowing quick and toolless changeovers between different labeling methods (e.g., hot melt, cold glue, self-adhesive, wrap-around) Versatility: Capable of han ...

Overview This Krones Linatronic M empty bottle inspector, manufactured in 2015, is designed for the reliable inspection of returnable glass bottles in beverage production lines. The system combines multiple inspection technologies including camera-based vision systems, infrared sensors, and high-frequency detection, ensuring the identification of contamination, residual liquids, closure issues, and bottle defects. With a capacity of up to 15,000 bottles and more per hour, the machine is well suited for medium-capacity bottling lines. The unit is equipped with a 3-fold Ecopush rejection system and supports a wide range of bottle types and glass colors, making it a flexible solution for breweries and beverage producers. Technical data Manufacturer: Krones Model: Linatronic M Machine type: Empty bottle inspector Year of manufacture: 2015 Capacity: up to approx. 15,000 bottles per hour and  ...

Overview This Krones Linapac A-T-1600 automatic bottle unpacker was manufactured in 1998 and was previously installed in a returnable glass beer bottling line. The machine is designed to automatically remove empty bottles from beverage crates and transfer them onto the bottle conveyor system for further processing. The unpacker was operated in a production line with a capacity of approximately 33,000 bottles per hour, making it suitable for high-capacity returnable glass operations. Machines of the LINAPAC series are widely used in the beverage industry due to their robust design and reliable crate handling. The machine is currently out of production but complete, electrical disconnected, and available for inspection. Documentation and CE conformity are available. Technical Data Manufacturer: Krones / Linapac Model: A-T-1600 Machine type: Automatic bottle unpacker Year of manufacture: 19 ...
