24 POREBA macchina utilizzata in vendita

- Carico di lavoro supportato 2 2 Kg stabili - Carico di lavoro non supportato 16000 Kg - inclusi 4 mandrini 1600 mm - inclusi 2 x Supporto stabile - incluso attacco interno per la levigatura - incluso attacco esterno per la levigatura - incluso supporto per la sella per fresatura

POREBA TCF 160 is a heavy-duty CNC horizontal lathe (turning machine) manufactured by POREBA Machine Tools, a Polish industrial machine tool builder. It’s part of the TCF series, which includes several sizes designed for machining very large, heavy workpieces such as shafts, rolls, and other long cylindrical components. Turning large shafts and heavy cylindrical parts, like those used in shipbuilding, power generation, mining, and heavy machinery. When equipped with optional tooling, it can also perform drilling and milling operations in addition to turning. Rigid construction with hardened guideways and heavy cast components for stability. Milling attachment 5,5 kW with Sk-40 taper Central lubrication Motorized tailstock 4 Chuck 1300 mm   CNC control SIEMENS 840D with following softeare options: MMC Easy Mask Spline interpolation Look Ahead Contour re-alignment  ...

Key data: 900 mm, 5000 mm

Sony Digital Read 2 assi Accessorio per la rotazione conica Riposo stabile 4 pezzi Autocentramento a 3 mandibol Indipendente per il mandrino a 4 mascelle Sistema di raffreddamento

- L'allunetta 1 è 150 mm - L'allacciatura 2 è 350 mm- L'allaccia 3 è 500 mm- 3 unità adatte per TPK 90 (o con distanziali TPK 110)- I distanziali non sono inclusi- 2e Portautensili da montare sulla slitta

diametro di tornitura su supporto slitta: 940 mm pertura di rotazione: 10000 mm diametria di rotazione: 1250 mm dia diametro del spino: 105 mm velocità: 1,6 - 315 (x24) m/min tensione: 380 V potenza totale: 75 kW peso della macchina ca.: t dimensioni della macchina ca.: m piatta a 4 ganasce Suosta di potenza

diametro di tornitura sul letto: 800 mm diametro di rotazione su supporto scorrevole: 530 mm lunghezza di rotazione: 8000 mm diametro di rotazione in gap: 1080 mm diametro del mandrino: 95 mm velocità: 8-800 (21x) U/min potente di potenza totale: 15/22 kW peso della macchina ca.: t dimensioni della macchina ca.: m 4-chuck Jaw 3-Jaw 2x Steady Rest 4-Way toolpost

Questa macchina di tornatura orizzontale Poreba TPK 90/5M è stata prodotta nel 1984. Presenta un piano oscillante di 930 mm, un diametro dell'alesa del mandrino di 95 mm e può gestire pesi fino a 9.000 kg con due appoggiamenti stabili. Include un controsportello, una pompa per il liquido refrigerante, una protezione per mandrini e un portautensili. Considera l'opportunità di acquistare questa macchina di tornatura orizzontale Poreba TPK 90/5M. Contattaci per maggiori informazioni su questa macchina.

Diametro di tornitura 900 mm Lunghezza di tornitura 5000 mm

Key data: 2500 mm, 8000 mm

Tornio modulare CNC per impieghi gravosi Poreba TZB-250 Controllo CNC Fanuc Oi-TF con pendente MPG (retrofit 2015), mandrino a piastra frontale a 4 griffe da 78,74", letto oscillante da 98,42", lunghezza massima di tornitura 314,96", distanza massima di oscillazione da 125,98", velocità del mandrino 0,5-1000 giri/min, foro del mandrino da 4,13", portautensili a 4 vie, capacità di peso approssimativa di 35.275 libbre (non supportata), contropunta elettrica, lunetta aperta, motore mandrino da 75 CV, s/n 1132 070

turning diameter over bed:930 mm turning diameter over slide rest:630 mm turning length:6000 mm turning dia. in gap:1250 mm spindle bore:95 mm turning speed range:8 - 800 U/min total power requirement:25 kW dimensions of the machine ca.:9 x 2 x 1,9 m faceplate 2 steadies coolant attachment taper turning attachment

turning diameter over bed: 1930 mm turning diameter over slide rest: 1520 mm turning length: 5000 mm turning speeds: 0,5-250 U/min spindle bore: 105 mm workpiece weight: 35 t steady: 400-700 mm steady: 700-1200 mm steady: 1000-1600 mm control: Siemens total power requirement: 106 kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Mark ...

turning diameter over bed: 1350 mm turning diameter over slide rest: 1020 mm centre distance: 6000 mm turning speeds: 5-500(x24) U/min spindle passage: 120 mm turning dia. in gap: 1700 mm total power requirement: 27/41 kW weight of the machine ca.: t dimensions of the machine ca.: m Power compound 4-jaw chuck, Ø 1.000 mm Steady rest, Ø 500 mm Work rest Rapid tool post Coolant system Rapid traverse 2-Axis Trak D.R.O. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 800 mm turning diameter over slide rest: 530 mm turning length: 8000 mm turning dia. in gap: 1080 mm spindle diameter: 95 mm speed: 8-800 (21x) U/min total power requirement: 15/22 kW weight of the machine ca.: t dimensions of the machine ca.: m 4-Jaw chuck 3-Jaw chuck 2x Steady Rest 4-Way toolpost The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 930 mm turning diameter over slide rest: 630 mm turning length: 6000 mm turning dia. in gap: 1250 mm spindle diameter: 95 mm speed: 8-800 (x24) U/min total power requirement: 22 kW weight of the machine ca.: 1100 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 800 mm turning diameter over slide rest: 540 mm turning length: 3500 mm turning dia. in gap: 1100 mm spindle diameter: 95 mm speed: 6 - 630 (18x) U/min chuck diameter: 3-jaw 400 mm chuck diameter: 4-jaw 700 mm total power requirement: 22 kW weight of the machine ca.: t dimensions of the machine ca.: m Power compound 4 way toolpost Steady rest Ø 400 mm 3 Axis D.R.O. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 2000 mm turning diameter: 2500 mm turning speeds: 0,5-100 U/min max. workpiece weight -without tailstock: 6000 kg max. workpiece weight between centres: 25000 kg Plate area: mm turning diameter in the pit: 3200 mm total power requirement: 55 kW weight of the machine ca.: t dimensions of the machine ca.: 22x5x4 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Te ...

turning diameter over bed: 1100 mm turning diameter over slide rest: 740 mm turning length: 6000 mm spindle bore: 110 mm turning speeds: 16-1600 U/min digital readout: faceplate: mm 3-jaw chuck: steady: total power requirement: 22 kW weight of the machine ca.: 11 t dimensions of the machine ca.: m Year of manufacture 1999 Control: Siemens 840D Turning length (mm) 6000 Max. turning diameter (mm) 1100 Max. turning diameter over slide (mm) 740 Spindle diameter (mm) 105 Speed 16 - 1800 (18x) kW 22 Voltage 380V Hz 50 3-jaw chuck ø (mm) ¦ 4-jaw chuck ø (mm) ¦ Fixed steady rest ø (mm) 2x Through-spindle cooling ¦ Multifix tool post The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space,  ...

turning diameter over bed: 1250 mm turning diameter over slide rest: 940 mm turning length: 6000 mm centre distance: 6200 mm spindle speed:: 1.6-315 U/min tailstock quill diameter: 200 mm workpiece weight: 30 t workpiece weight max.: 40 t steady: 3 digital readout: total power requirement: kW weight of the machine ca.: 25 t dimensions of the machine ca.: 11x2,4x1,9 m drive motor: 75 kW The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointmen ...

Diametro di rotazione sul letto/slitta trasversale: 700 mm/430 mm, lunghezza di tornitura: 4000 mm, foro del mandrino: 80 mm, velocità: 1500 giri/min, larghezza del letto: circa 550 mm. Dimensioni della macchina X/Y/Z: circa 6300 mm/1350 mm/2000 mm, peso: circa 5700 kg. È possibile un'ispezione in loco.

turning diameter: 1100 mm turning length: 6000 mm control: Siemens 840D turning diameter over slide: 740 mm total power requirement: 22 kW weight of the machine ca.: t dimensions of the machine ca.: m Die Maschine ist Überholt und hat eine neue Steuerung The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 930 mm turning diameter over slide rest: 630 mm turning length: 8000 mm speed: 800 U/min spindle passage: 105 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

diametro oscillazione: 430 mm altezza punte: 450 mm potenza totale richiesta: . kW peso della macchina ca.: t dimensioni della macchina ca.: m

diametro oscillazione: 430 mm altezza punte: 450 mm potenza totale richiesta: . kW peso della macchina ca.: t dimensioni della macchina ca.: m

diametro di tornitura: 630 mm costanza di tornitura: 2000 mm controllo: Zyklen gesteuert stastanza: 2 Stk. potenza totale richiesta: kW peso della macchina ca.: t dimensioni della macchina ca.: m
