Costa SA TS 1350

Technical Specifications:
- Manufacturer: Costa
- Model: SA TS 1350
- Year of manufacture: 2005
- Working width: 1,350 mm
- Sanding belt dimensions: 2,620 x 1,380 mm
- Sanding heights: 3–160 m
- Feed speed: 5–25 m/min.
- 1st Unit:
- Longitudinal sanding unit
- Belt dimensions: 2,620 x 1,380 mm
- Electronic sanding shoe, Costa system
- roller spacing: 32 mm
- Segment width: 32 mm
- Drive motor power: 11 kW
- Dust removal brush diameter: 180 mm
- Operator side: left
- Height adjustment: motor
-driven
- Vacuum conveyor belt
- Total power connection: 20 kW / 43 A
- Width: 1,924 mm
- Length: 2,059 mm
- Height: 2,185 – 2,375 mm
- Exhaust connections: D 2x100 mm + 2x160 mm
- Airflow: 4,830 m³/h at 24 m/s
- Compressed air: 6 bar, 880 NL/min.
- Volts, Hz: 400 / 50
- Voltage fluctuations: max. ±5%
- Weight: 3,100 kg
- Location: Blomberg warehouse
