macchine per taglio ingranaggi e dentatrici usati in vendita (228)

weight of the machine ca.:4 t

total power requirement:413 kWInduction hardening machine Rotary table Eldec: Z (servo drive 750 mm Y (electromechanical) 300 mmX (electromechanical) 200 mmMaximum part diameter 600 mmMaximum workpiece weight 500 kg High frequency generator type HFG 200 Medium frequency generator type MFG 30

max. wheel diameter:200 mmgear width:60 mmmax. module:7 weight of the machine ca.:15 ttable diameter:180 mmtable turning speeds:100 U/minhob turning speeds:750 U/minMachine in good condition, without feed, without automationAvailable 24.08.2024

max. wheel diameter:900 mmmax. module:10 weight of the machine ca.:8200 kos.hob dia. - max.:190 mmcutter length max.:320 mmmilling spindle speeds (infinitely variable):13-80 U/minworkpiece length - max.:750 mmmax. workpiece diameter:150 mmCounter holder milling mandrel is missing

max. wheel diameter:280 mmmax. module:5 min. module:1 min. number of teeth:7 toolpiece turning speed range:4.000...10.000 U/mintool length:210 mmCBN

max. wheel diameter:200 mmgear width:50 mmmax. module:6 table diameter:168,14 mmboring diameter:65,532 mmweight of the machine ca.:11 ttable turning speeds:0-1.000 U/minlength of stroke min./max.:0-70 mmno. of strokes:180-1.800 Stück

max. wheel diameter:300 mmgear width:110 mmmax. module:6 weight of the machine ca.:10,5 t

max. wheel diameter:300 mmgear width:60 mmmax. module:5 weight of the machine ca.:14 ttable turning speeds:80 - 200 U/minadjustment movement of the stroke:400 mmlength of stroke min./max.:0-70 mmno. of strokes:1500 Hub/min

max. wheel diameter:210 mmtotal power requirement:60 kWweight of the machine ca.:8 tdimensions of the machine ca.:2,85 x 2,60 x 1,80 mgrinding slide feed:700 mmgrinding slide feeds:1-15.000 m/minmax. workpiece weight:150 kgcentre height:260 mmgrinding wheel diameter:240 mm

rotor dia:30-500 mmhobbing length:500-1000 mmtotal power requirement:80 kWweight of the machine ca.:15 tdimensions of the machine ca.:3,6 x 2,5 x 3,0 mmax. module:8 Max. module Et milling = 12 Max. module hobbing = 12 Max. axial travel = 110 to 1100mm Max. cutter speed = 300rpm Max. cutter displacement tangential = -350 to -55mm Max. table speed = 100rpm Table drive: torque motor Filter system: chip conveyor is for magnetic materials, belt filter is for all suspended matter that floats in the oil Including milling mandrel

max. wheel diameter:275 mmgear width: mmmax. module: weight of the machine ca.:9,4 tdimensions of the machine ca.:3,7 x 3 x 2,82 mmin. number of teeth:5 max. number of teeth:2000 range of tooth size:20 mmmax. gear width (internal machining):58 mmX-axis:325 mmy-axis:350 mmZ-axis:475 mmBevel gear milling machine Gleason Pfauter including Promot Automation

max. module:7 weight of the machine ca.:5 tworm grinding diameter:280-350 mmwidth of grinding worm:84-104 mmmin. number of teeth:6 max. number of teeth:600 max. top circle diameter:360 mmmax. workpiece weight:60 kgwithout filter

max. wheel diameter:80/120 mmmax. module:2,5 max. top circle diameter:65 mm:22 mm:140 mm:120 mmslide travel axial ( Z-axis ):320/400 mmDimensions (L/W/H):3270 x 3240 x 2020 mmweight of the machine ca.:6 tP60 - The compact all-rounder for wheels, shafts and wormsThe P60 is the smallest machine in the Gleason line of horizontal hobbing machines. The all-rounder not only mills spur gears with all rollable profiles, but is also the optimal solution for machining steering pinions and worms.with automatic loading system, extraction unit, chip conveyor, with balancing device with 2 tailstocks, with Artec process monitoring system, type CTM-BT1.1

Infeed and outfeed chain conveyor, with tool holders, chip conveyor, hydraulic unit and air conditioning.

max. wheel diameter:600 mmmax. module:6 weight of the machine ca.:0,9 tdimensions of the machine ca.:1,52 x 0,91 x 1,45 m

max. wheel diameter:300 mmmax. number of teeth:999 max. module:5 total power requirement:10 kWweight of the machine ca.:1.800 Kos.dimensions of the machine ca.:1300 x 1450 x 2250 mmThe Gear Tooth Deburring machine ? ZEM 300for deburring of splines gear wheels and shaftsThe advantages at a glance- Vertical workpiece spindle- Chamferring, debburing and smoothing - Simultaneous Processing of 2 Gears- Dry Processing- Repeat accuracy when adjusting the tools- Simple integrated Pick up swing arm or linear loader- Crane hook machineWorkspace Swing Diameter: 300 mmProcess Diameter: 300 mmWorkpiece Length: 450 mmMain Spindle Spindle Flange: Zylindrisch D=120 mmFront bearing spindle: 100 mmRPM max: 1500 U/minAC-Synchronmotor: 50 NmClamping cylinder : pneumaticClamping force (5 bar): 10 kNWorking axis swing arm for chamferring tool Feed force: 3 kNBall screw drive: 25x5Position meas ...

max. wheel diameter:600 mmmax. module:10 min. module:2 total power requirement:1,4 kWweight of the machine ca.:0,68 tdimensions of the machine ca.:1,6x0,75 mdiameter of hob:15 mmgear width:140 mm

max. wheel diameter:300 mmgear width:100 mmmax. module:5 workpiece turning speeds:0 - 1000 1/minwork piece - max.:1100 mmworkpiece clamping:auto. tension device number of spindle speeds:1000 1/min.spindle bearing diameter:100 mmdiameter of spindle flange:120 mmtailstock travel:80 mmweight of the machine ca.:3500 KGdimensions:1200 x 1450 x 2250 mmtotal power requirement:10 kVAThe Gear Tooth Deburring machine WERA, ZEM 300 for deburring of splines gear wheels and shafts, with Pointing Facility.

max. wheel diameter:5 - 260 mmgear width:400 mmmax. module:15 min. module:0,5 gear hobbing diameter - internal:30 mmmax. helix angle:> 85 ° Aussenverz.max. helix angle:> 45° Innenverz.Testing Range vertical:400 mmdist. between centers:5 - 600 mmtable diameter:260 mmmax. table load:100 kgspeeds:30 1/mintotal power requirement:1,6 kVAweight of the machine ca.:900 kgdimensions of the machine ca.:200 x 1300 x 2150 mmCNC Gear Tester in good condition, out of OEM Test Lab.For measuring of spur and helical toothing, additional of rotationally symetric parts as true running, coaxiality, axial runout, etc. with tool changer ( 4 nos.)

max. wheel diameter: 180 mmgear width: ca. 220 mmmax. module: 3 / 5 mmControl: Siemens 840D sl max. radial velocity: 5000 mm/minmax. workpiece diameter: 180 mmtable rotation speed: 800 U/mintable diameter: 145 mmaxial travel: 250 mm mmback rest:: axial travel: 300 mmclamping force max.: 13 kNmilling head:: swivelable +/-: 45 °drive capacity: 23 kWturning speeds: 6000 U/mindiameter of tools max.: 90 mmtool clamping length max.: 211 mmmodule hobbing max.: 3 module profile milling max.: 5 tangential speed max.: 7500 mm/minweight of the machine ca.: 9,5 tdimensions of the machine ca.: 4,5 x 3,5 x 2,7 mEquipment / Accessories:- The machine is equipped for dry milling.- workpiece magazine- parallel gripper: - workpiece weight form-fit max. 15 kg - workpiece length max. 400 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

hobbing length: 1750 mmmilling width: 260 mmmax. module: 10 mmtable size incl. water gutter: 460 x 2100 mmtable clamping surface:: 250 x 1850 mmcutter width - max.: 100 mmfeed of the milling slide, stepless: 0 - 500 mm/min.rapid traverse feeds: 3000 mm/minmilling head -swivable +/-: 30 °Rotation speed range of milling head, in 9 steps: 29 - 178 rpmMilling head swivable 2 sides helical gearcutting: 30 °total power requirement: kWweight of the machine ca.: 4 tdimensions of the machine ca.: 4 x 1,85 x 1,85 mEquipment/accessories- 7 vices- change wheels - Clamping devices- DocumentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Diametro massimo della ruota: MmGear Larghezza: mmmax. modulo: 0min. modulo: 0 Consumo totale di energia: kWweight della macchina ca.: tSpazio richiesto: m I dati per questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.

Diametro massimo della ruota: MmGear Larghezza: mmmax. modulo: 0min. modulo: 0 Consumo totale di energia: kWweight della macchina ca.: tSpazio richiesto: m I dati per questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.

Diametro massimo della ruota: MmGear Larghezza: mmmax. modulo: 0min. modulo: 0 Consumo totale di energia: kWweight della macchina ca.: tSpazio richiesto: m I dati per questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.

max. wheel diameter: 630 mmgear width: 425 mmtable hole: 125 mmclamping table: 550 mmmax. module: 10 axial-feeds: 0,40 - 6,80 mm/Uradial feeds: 0,10 - 1,76 mm/Udist. cutter spindle - workpiece spindle: 50 - 425 mmno. of teeth: min. 8 milling cutter dia. x width: 192 / 215 mmshifting: 200 mmmain drive motor: 7,5 kWtotal power requirement: 22,5 kVaweight of the machine ca.: 8,2 tMachine equipment:- Universal milling head with tangential displacement- Pressure reducing valve for counterholder- Magnetic chip transport--> Working range Largest module to be milled (in steel 600 N/mm²): 10 mm--> Straight gear teeth:--> Largest workpiece diameter: 630 mm--> Largest axial slide travel (Z-axis): 425 mm--> Smallest number of teeth to be milled: 8--> Dimensions Diameter of workpiece table: 550 mm--> Diameter of table bore: 125 mm--> Diameter of workpiece mandrel: 36 mm--> Largest milling cutter t ...

max. wheel diameter: 3000 mmgear width: 500 mmmax. module: 25 / 40 spindle turning speed range: 250 U/minfeed speeds: max. 4000 mm/minfaceplate diameter: 2000 mmtable bore diameter: 700 mmtable turning speeds: 51 U/minpower capacity - milling spindle: 53 kWdrive motor for milling spindle: - kWaxial adjustment: 1200 mmmilling head swivable ca.: +/- 45 °control: Siemens 840D total power requirement: - kWweight of the machine ca.: 55 t- CNC Control Siemens 840D- Internal Hob Head IFK- External Hob HeadThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Diametro massimo della ruota: 250 mm, larghezza del marcia: 250 mm. Modulo: 6 min. Modulo: - Consumo totale di potenza: 22 kWweight della macchina ca.: 6 tDimensioni della macchina ca.: 1,9 x 1 x 1,8 m - Cambio marcia - Trasportatore a chip - Assi del filtro - Strumenti di serraggio I dati per questo annuncio sono stati creati con ModulMWS - la soluzione software di LogoTech oHG.

max. wheel diameter: 1250 mmgear width: 600 mmmax. module: 16 min. module: 2 tooth width: 490 mmZahnschrägungswinkel max.: 45 °shifting: 200 mmmax. number of teeth: 12 diameter of hob: 240 mmcutter length max.: 280 mmtable diameter: 1020 mmmilling spindle speeds (infinitely variable): 28 - 200 U/minpower capacity: 25 kWweight of the machine ca.: 16,2 tdimensions of the machine ca.: 4,5 x 4,6 x 2,7 mequipped with:- universal hob head- change gearsmachine has been partly overhauled (electrical and machnical) and is now with programmable, digital InfeedThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 2500 mmgear width: 750 mmmax. module: 18 / 22 min. module: table diameter: 1800 mmmin. number of teeth: 12 table hole: 300 mmhob turning speeds: 20 - 100 U/mintable load: 10 tmilling cutter dia. x width: 250 x 340 mmshifting: 150 mmfeeds - tangential: 0,25 - 3 mm/minfeeds - radial: 0,07 - 1,5 mm/minfeeds - longitudinal: 0,55 - 3,5 mm/minmilling feeds: 13,4 - 80 (Einzelteilen) mm/mintotal power requirement: ca. 30 kWweight of the machine ca.: 28 t- change gears, arbors, toolings, clamping plots- universal hob head- swiveling outer steady - single indexing deviceparty overhauled in 2023The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
