lavorazione della lamiera usati in vendita (3,292)

material width:150 mmmaterial thickness:2,5 mmfeed length:100 mmcompressed air:6 barclamping force of fastening pincer:2000 Nclamping force of moving pincer:2000 Nfeeding force:1200 Nweight:0,1 tDimensions (WxDxH):0,35 x 0,85 x 0,5 m

Working hours laser on: 50921 h Working hours beam on: 21717 h Laser power: 3200 Watt Working range laser: 4000 x 2000 x 115 mm Max. steel: 20 mm Max. stainless steel: 12 mm Max. aluminium: 8 mm Length: 11600 mm Width: 5300 mm Height: 2200 mm Machine weight: 16000 kg Electrical connected load: 73 kVA

material width:850 mmmaterial thickness:0,3 - 1,5 mmno. of straightening rolls:8 straightening roll diameter:40 mmnumber of draw-in rolls:2 diameter of draw-in rolls:160 mmmaterial thickness with 600 mm material width:1,9 mmmaterial thickness with 400 mm material width:2,3 mmspeed:5 - 25 m/minmin. material width:200 mmweight:2,8 tDimensions (WxDxH):1,6 x 2,2 x 2,3 m

Working hours machine: 23304 h Working hours laser on: 22804 h Working hours beam on: 10185 h Laser power: 4400 Watt Working range laser: 3000 x 1500 mm Max. steel: 25 mm Max. stainless steel: 20 mm Max. aluminium: 12 mm Length: 12800 mm Width: 6300 mm Height: 2400 mm Machine weight: 15000 kg Electrical connected load: 51 kVA

material width:850 mmmaterial thickness:0,3 - 1,5 mmno. of straightening rolls:8 straightening roll diameter:40 mmnumber of draw-in rolls:2 diameter of draw-in rolls:160 mmmaterial thickness with 600 mm material width:1,9 mmmaterial thickness with 400 mm material width:2,3 mmspeed:5 - 25 m/minmin. material width:200 mmweight:3,1 tDimensions (WxDxH):2,2 x 1,5 x 2,8 m

material width:300 mmmaterial thickness:- 3,0 mmno. of straightening rolls:7 Stückstraightening roll diameter:60 mmweight:0,8 tDimensions (WxDxH):0,9 x 1,5 x 1,4 m

table length:2000 mmtable width:600 mmtable height:300 mmmounting surface:700 x 600 mmcentre distance:1200 mmcentre height:160 mmDimensions (WxDxH):2,0 x 0,6 x 0,3 m

material width:380 mmcoil weight:1,0 tmaterial thickness:2,5 mmcoil external diameter:1000 mmno. of straightening rolls:7 straightening roll diameter:50 mmnumber of draw-in rolls:2 diameter of draw-in rolls:90 mmweight:0,8 tDimensions (WxDxH):0,8 x 1,3 x 1,7 m

material width:500 mmmaterial thickness:0,6 - 1,6 mmno. of straightening rolls:7 straightening roll diameter:60 mmnumber of draw-in rolls:2 + 2 inlet roll diameter:60 mmmax. material thickness:2,0 mmmaterial thickness at 150 mm material width:2,0 mmmaterial thickness at 500 mm material width:1,6 mmweight:0,5 tdimensions (WxDxH):0,8 x 1,0 x 1,2 m

material width:400 mmcoil weight:3,0 tmaterial thickness:0,5 - 4,0 mmcoil internal diameter:460 - 530 mmcoil external diameter:1500 mmno. of straightening rolls:9 straightening roll diameter:50 mmno. of lower support rolls:12 no. of upper support rolls:10 diameter of support rolls:90 mmmaterial cross-cut:1600 mm²speed of coil line:0 - 20 m/minpower requirement:35,0 kWweight:10,5 tdimensions (WxDxH):10,0 x 2,5 x 2,9 mstraightening machine:KRE 50.400/9 adjustment of straightening rolls :motoric insertion wedge:hydraulic adjustable decoiler:3000.1 snubber roll:hydraulic expansion:hydraulic sideway adjustment:motoric pivoting:manual roll feed:Servo; WVE 160/400 intermittant lifting:hydraulic

material width:300 mmmaterial thickness:0,6 - 2,5 mmno. of straightening rolls:7 straightening roll diameter:60 mmnumber of draw-in rolls:2 + 2 diameter of draw-in rolls:60 mmmax. material thickness:3,5 mmmaterial thickness at 30 mm material width:3,0 mmmaterial thickness with 300 mm material width:2,5 mmweight:0,3 tDimensions (WxDxH):0,9 x 1,0 x 1,1 m

material width:550 mmmaterial thickness:0,4 - 1,6 mmno. of straightening rolls:11 straightening roll diameter:60 mmnumber of draw-in rolls:4 diameter of draw-in rolls:60 mmband speed:4 - 50 m/minpower capacity:3,0 kWweight:1,7 tDimensions (WxDxH):2,5 x 2,0 x 1,7 m

material width:320 mmcoil weight:2,6 tmaterial thickness:0,5 - 2,0 mmcoil internal diameter:400 - 510 mmcoil external diameter:1200 mmno. of straightening rolls:7 straightening roll diameter:50 mmnumber of draw-in rolls:2 band speed:0 - 30 m/minpower capacity:1,5 kWweight:1,5 t

material width:120 mmmaterial thickness:0,4 - 4,0 mmno. of straightening rolls:19 straightening roll diameter:24 mmmaterial cross-cut:120 mm²:40 mmbending speed:5 - 25 m/minweight:0,85 tdimensions (WxDxH):1,2 x 1,7 x 1,6 infinitely variable drive:Stöber

material width:400 mmmaterial thickness:0,6 - 2,8 mmno. of straightening rolls:5 straightening roll diameter:40 mmno. of pulling rolls:2 + 2 material thickness at 400 mm material width:1,8 mmmaterial thickness at 65 mm material width:2,8 mmpower capacity:3,0 kWweight:0,45 tDimensions (WxDxH):0,8 x 1,8 x 1,35 m

material width:250 mmmaterial thickness:0,2 - 2,0 mmno. of straightening rolls:7 straightening roll diameter:60 mmrun-in height:1250 mmpower capacity:4,0 kWweight:0,65 tDimensions (WxDxH):1,05 x 1,25 x 1,5 m

plate thickness:4 mmblade length:180 mmweight of the machine ca.:21 kgdimensions of the machine ca.:400 x 100 x 1500 mm

material width:250 mmmaterial thickness:0,4 - 3,5 mmno. of straightening rolls:9 straightening roll diameter:30 mmspeed:3 - 15 m/minmaterial thickness at 250 mm material width:3,0 mmmaterial thickness at 200 mm material width:3,5 mmpower capacity:1,8 kWweight:0,9 tDimensions (WxDxH):1,45 x 1,4 x 1,55 m

Decoiler Coil weight: 2 x 2 ton Material width: 380 - 500 mm Coil exterior diameter: 1.300 - 1.400 mm Expansion range: 445 -530 mm Leveller / Straightener Material width : 40 - 500 mm Number of levelling rolls: 7 pcs. Diameter of the levelling rolls: 60 mm Number of pinch rolls: 2 pcs. Diameter of the drawing rolls: 60 mm Number of pull out rolls: 2 pcs. Diameter of the pull out rolls: 60 mm Material thickness: 0,4 - 1,6 mm Cross section: 800 sq mm Feeding speed: 0 - 30 m / min Required power: 3 kW

Coil weight: 500 kg Material width: 41 mm Coil exterior diameter: 1.000 mm Expansion range: 250 - 500 mm Speed: 20 m / min Required power: 0,5 kW Dimensions L x W x H: 1.000 x 850 x 1.700 mm Weight of machine approx.: 200 kg

material width:200 mmmaterial thickness:0,8 - 3,0 mmno. of straightening rolls:6 straightening roll diameter:53 mmnumber of draw-in rolls:2 diameter of draw-in rolls:96 mmmaterial cross-cut:400 mm²speed:3 - 15 m/minpower capacity:0,75 kWweight:0,5 tDimensions (WxDxH):1,0 x 1,0 x 1,4 m

material width:300 mmcoil weight:2 x 1,25 tmaterial thickness:0,4 - 1,2 mmcoil internal diameter:320 - 420 mmcoil external diameter:1300 mmno. of straightening rolls:9 straightening roll diameter:30 mmnumber of draw-in rolls:2 roll diameter:30 mmspeed:3 - 30 m/minfeed length:0 - 9999,9 mmpower requirement:3,0 + 2,5 kWweight of decoiler:0,7 tdimensions decoiler (WxDxH):2,1 x 1,4 x 1,5 mmweight of straightening machine:0,45 tdimensions straightener (WxDxH):1,5 x 0,8 x 1,1 mmweight of the feeder:0,4 tdimensions feeder (WxDxH):1,2 x 0,8 x 1,1 mmuniversal straightening machine:SC 12-FQ double decoiler:2352 B-FPS expansion:hydraulic lag brake:pneumatic electronic roll feed:WAV-RDS-2Z, Modell 1082 B intermittant lifting:pneumatic control:Siemens S 5

material width:150 mmcoil weight:1,5 tcoil internal diameter:500 mmcoil external diameter:940 mmstrip material:20 x 1,0 - 50 x 4,0 / 200 x 2,0 mmwire diameter:1,0 - 5,0 mmpower requirement:0,7 kWweight:0,7 tDimensions (WxDxH):1,0 x 1,7 x 2,0 mpalett decoiler:motoric driven

material width:300 mmcoil weight:0,5 tmaterial thickness:0,4 - 3,0 mmcoil internal diameter:420 - 520 mmcoil external diameter:1200 mmno. of straightening rolls:9 straightening roll diameter:50 mmnumber of draw-in rolls:2 diameter of draw-in rolls:50 mmpower requirement:1,5 kWweight:1,55 tdimensions (WxDxH):2,5 x 1,2 x 1,8 m

weight of the machine ca.:620 kgdimensions of the machine ca.:1000 x 920 x 1550 mm

material width:500 mmmaterial thickness:0,2 - 3,8 mmfeed length:0 - 9999,9 mmnumber of rolls:2 material cross-cut:128 mm²speed:60 m/minpower requirement:2,0 kWdimensions (WxDxH):1,2 x 1,3 x 1,5 mroll feed:Servo control:Siemens S 7, modification 2002

sheet width: 3190 mmplate thickness: 6 mmdistance between columns: 3250 mmcutting angle: 1,2 °no. of strokes: 32-75 Hub/mincolumn arm: 100 mmback stop - adjustable: 5-1000 mmtable height: 800 mmoil volume: 150 ltotal power requirement: 15 kWweight of the machine ca.: 6200 kgEquipment:- electro-hydraulic guillotine shear type swing cut”- RAS MULTICUT-ECO 2000” CNC control unit movable, from the front 3 axes control unit with up to 900 program lines Sheet holding device for thin sheet cutting can be switched on Including piece and cycle counter Operating modes selectable- CNC electro-motorized back gauge ... Travel range 5-1000 mm Traversing speed ... 180 mm/sec.- Front support plates with ball rollers- central motorized cutting gap quick adjustment- 1x RAS extra long side stop- 2x RAS extra long support arms- 1x free-moving foot switch- 1x RAS pneumatic sheet holding device for thin  ...

sheet width: 3100 mmplate thickness: 2.00 mmthickness at Niro-steel: 1.25 mmno. of strokes: max. 36 Hub/mincutting angle: 0.9 Gradtable height: 800 mmtable width: 430 mmdistance between columns: 3200 mmback stop - adjustable: 5.0 - 750 mmengine output: 3.0 kWweight of the machine ca.: 1950 kgrange L-W-H: 3730 x 2070 x 1400 mmFeatures:- Robust / motorized swing-cut guillotine shears- Machine with manual material/backgauge Travel range 5.0 – 750 mm stop depth Analog position display Manual adjustment from the front - Break-proof, torsion-free steel welded construction- Compact and clear machine design- 1x hold-down beam Hold-down opens before the knife beam moves up No kinking of very sensitive sheets- Manual cutting gap adjustment- Integrated sheet metal holding system for thin sheet metal cuts- Sheet metal/cut material removal at the front (operator side)- 1x side stop with mm scale- ...

material width:600 mmcoil weight:5,0 tmaterial thickness: - 5,0 mmcoil internal diameter:360 - 660 mmcoil external diameter:1500 mmno. of straightening rolls:9 straightening roll diameter:80 mmnumber of draw-in rolls:2 material cross-cut:1600 mm²weight of feeeder-straightener:2,5 tweight of decoiler:1,5 tdimensions feeder-straightener (WxDxH):1,7 x 1,7 x 2,6 mmdimensions decoiler (WxDxH):1,8 x 2,0 x 2,3 mmfeeder-straightener:VCRL 650, Bj. 1994, GR 2001 height adjustment:motorisch alligator opening:hydraulisch decoiler:SHR 5000, Bj. 2000 expansion:hydraulisch

sheet width: 3100 mmplate thickness: 6.35 mmthickness at Niro-steel: 4.00 mmcutting angle: 0.5 - 2.5 °cutting gap adjustment: 0.05 - 0.8 mmno. of strokes: 12 - 50 Hub/minback stop - adjustable: 1000 mmControl: DELEM DAC 360 oil volume: 120 ltr.engine output: 9.5 kWweight: 7000 kg.range L-W-H: 3950 x 1950 x 1680 mm well-maintained condition () equipped with new DELEM control unitEquipment:- electro-hydraulic, guided plate shear- DELEM CNC control unit type DAC 360 front control panel, swiveling front left- Electro-hydraulic cutting angle adjustment- Electro-hydraulic cutting gap adjustment- electro-motorized backgauge, with ball screws- 1x extra-long side fence with T-slot mm scaleThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
