altre macchine per l'industria alimentare usati in vendita (1,000)

Macchina verticale per avvolgimento a flusso con tecnologia di srotolamento del film, formazione della spalla e alimentazione per il confezionamento di materiali sfusi. Produttore: WOLF Verpackungsmaschinen GmbH Tipo: VPP-350 Anno di realizzazione: 2001 Numero macchina: 0550 Numero di serie: 2.01.027 Metodo di confezionamento: Avvolgimento a flusso verticale Alimentatore di pellicola: rullino di pellicola con guida al film Formatura del film: formatura della spalla e formazione del tubo Finitura materiale: Rivestimento in acciaio inox Tecnologia di alimentazione: nastro trasportatore ascendente con trasportatori e tramoggia in acciaio inox Funzionamento: Pannello di controllo e visualizzazione digitale Trattamento dell'aria compressa: SISTEMI DI CODIFICA ALLEN Pressione di ingresso aria compressa: 4–10 bar (indicata sul regolatore dell'aria compressa) Pressione di usci ...

Sistema di manipolazione automatizzato per la raccolta, il posizionamento e il trasferimento di prodotti da forno o biscotti all'interno di una linea di produzione. Produttore: Schubert Tipo di macchina: Sistema pick-and-place / sistema di manipolazione e trasferimento Anno di produzione: 2005 Applicazione: Produzione di panificazione e biscotti Controllo: Pannello di controllo touchscreen Modalità di funzionamento: automatica, manuale e funzioni di servizio Trasporto prodotto: Sistemi a nastri trasportatori a più corsie Sistema di manipolazione: unità automatizzate di presa e riposizionamento Attrezzature: Piattaforma di manutenzione con ringhiera, sistema di estrazione e ventilazione, interruttore di arresto d'emergenza Produttore del ventilatore: Rosenberg Tipo di ventola: RS 200 L (U05-07) Potenza della ventola: 0,160/0,21 kW Velocità della ventola: 2540/2690 giri ...

Complete industrial margarine production line with a nominal production capacity of approximately 1.500 kg of table margarine per hour with a work product pressure up to 120 bar. The processing tanks and process design is made by GEA. The High Pressure Pump, Crystalliser and Pin Rotors are made by Gerstenberg Schröder / SPX - Perfector. The consumer packaging machine is made by Oystar Benhil Ecopack. The entire line is still installed in its original position at the factory in India, offering an excellent opportunity for inspection and evaluation in its existing production environment., Fat spreads consist of two primary phases: a water phase and a fat phase. They are therefore classified as water-in-oil (W/O) emulsions, in which the water phase is finely dispersed in the form of small droplets throughout the continuous fat phase. Depending on the intended application and required produ ...

The Alfa Laval SRU6/260/LS is a robust positive displacement lobe pump designed for the gentle and efficient handling of sensitive process fluids. Engineered in accordance with the most stringent hygienic design standards, the pump features fully validated and effective Cleaning-in-Place (CIP) capability. The SRU pump range is suitable for applications across the dairy, food, beverage, brewing, chemical, pharmaceutical, and home and personal care industries. Its smooth, low-shear pumping principle allows for the handling of products with a wide range of viscosities—from low to very high—including creams, gels, emulsions, aerated mixtures, and media containing delicate cells or organic solids in suspension. Products containing fragile solids, such as curd, can be transferred without damage due to the specially designed tri-lobe stainless steel rotors. The pump has a nominal displaceme ...

Automatic foil wrapping machine designed for packing butter and similar products in aluminium foil. The machine was previously used in a butter production facility and operates with the SIG folding principle, featuring a side folding flap to minimise foil consumption., The machine is equipped with a rotating forming drum with 4 rectangular moulding chambers, designed for a 250 gram butter format with dimensions of approximately 106 × 65 × ± 38 mm. The butter is fed into the machine via an aluminium trough fitted with augers, ensuring a continuous product supply to the wrapping section. A photocell is installed at the foil infeed to detect the exact position of the printed packaging material, ensuring accurate alignment of the print on each wrapped product., The machine speed is adjustable by means of a frequency converter, allowing the operating speed to be adapted to the product char ...

Egli butter reworking line designed for processing and reworking frozen or chilled butter blocks with a core temperature above ± 0 °C. The installation is suitable for industrial butter processing applications where solid butter blocks need to be broken down and prepared for further processing. The line consists of a butter bulk conveyor, Egli, EBSCM 7, V-6000-2, block shredder with a motor of 7,5 kW and Egli, EBW34 reworking silo of 5.000 liter, equipped with 2x augers with a motor of 9 kW and a reduced speed of 6,8 - 27 rpm. The bulk conveyor feeds the butter blocks into the shredder, where the butter is reduced into smaller pieces. The shredded butter is subsequently transferred into the reworking silo, where the twin augers ensure controlled product movement and facilitate further processing. The installation is designed for hygienic food processing and is CIP-cleanable (Cleaning-i ...

Tetra Pak Tetra Alex 2 (TA2/200BAR) high-pressure homogeniser, designed for the homogenisation of milk, dairy products and other liquid food products., The machine is equipped with a 3-cylinder homogenising block and a single-stage homogenisation system with mushroom-type valves. The maximum design capacity is up to 6,500 litres per hour at a maximum pressure of 160 bar. With the currently installed 30 kW motor, the machine is configured for a capacity of approximately 4.000 litres per hour at an operating pressure of up to 200 bar with a piston diameter of 40 mm. The homogeniser is equipped with hydraulically operated pressure-setting valves, mounted on the side panel, allowing adjustment of the homogenisation pressure. A pressure gauge is installed to monitor operating pressure and pulsation dampers are ensure smooth product flow. The machine also features an integrated oil pumping sys ...

Universal processing machine manufactured by Marcos Inox, suitable for the preparation and processing of a wide range of products, including processed cheese, convenience foods, vegan spreads and confectionery. The machine is equipped with an electrically driven agitator for efficient product mixing, featuring a 3.3 kW motor operating at 380–420 V and 7.8 A. The lid incorporates injection ports for the direct injection of culinary steam into the product, as well as an integrated temperature sensor for monitoring the product temperature during processing. The double-jacketed processing bowl is designed for temperature-controlled processing. The bowl can be hydraulically tilted to facilitate product discharge. The lid is hydraulically operated and can be raised to a vertical position, providing convenient access to the bowl for loading, inspection and cleaning. The machine is fitted with ...

APV Direct Steam Injection (DSI) Uperizer UHT processing Plant with Aseptic Homogeniser, previously used for the sterilisation of milk and dairy products. The installation has a processing capacity of 7.600 litres per hour and is designed for high-temperature sterilisation at temperatures of up to 150°C., The system utilises direct steam injection for rapid product heating, followed by flash cooling under vacuum to achieve the desired processing temperature. The line is equipped with an APV Gaulin MC 45-5TPSX aseptic homogeniser, ensuring efficient homogenisation under high pressure for consistent product quality., In the Uperizer head, pure, culinary-grade steam is injected directly into the product flow under high pressure. This causes the temperature to rise almost instantaneously—within fractions of a second—to between 140 °C and 150 °C. The milk is then held at this temperatu ...

Serviced Continuous Butter Making Machine (CBM) equipped with a new Rittal control panel with simple and user-friendly controls. Stainless Steel frame execution. The machine is designed for the continuous production of sweet butter from cultured and / or sweet cream and is suitable for hygienic dairy processing applications. The CBM has a butter production capacity of approximately 1.500 kg per hour and is designed for an input of approximately 3.000 litres of cultered or / and sweet cream per hour (38/42% fat, pH of 4,5/4,8 and infeed temperature ± 10 - 13 °C). Completely electrically driven; Churning cylinder / Beater I: 22 kW, Churning cylinder II: 2,2 kW and Squeezer / Working section: 5,5 kW., The machine is equipped with a new Rittal electrical control panel, incorporating simple and clearly arranged controls for the main machine functions. The control panel includes:, - 3 x Danf ...

The Tetra Pak Tetra Alex Modified” 25 (TAM25/160BAR) is an industrial, three-cylinder high-pressure homogeniser designed for the homogenisation of milk and other liquid food products. The machine has a maximum design capacity of up to 12.600 litres per hour at a maximum pressure of 160 bar. With the currently installed motor, the capacity is set at approximately 10,000 litres per hour at 160 bar. The homogeniser is equipped with a two-stage homogenisation system featuring mushroom-type valve cylinders, ensuring efficient and consistent product homogenisation. The operating pressure can be hydraulically adjusted via the controls on the front panel. Pressure gauges are installed for monitoring the operating pressure. The machine features a stainless steel-clad exterior and an integrated oil pumping system for lubrication. It is driven by a 55 kW electric motor and supplied with a control ...
